Dimensions (HxWxL):
|
17.2 x 7.7 x 15.0 cm
|
|
Weight:
|
375 g / 13.2 oz (including battery & trigger handle).
|
|
User input:
|
Trigger button.
|
|
User feedback:
|
Speaker, vibration motor, LED.
|
|
Power:
|
Removable, rechargeable 3.7V, 2400mAh, 8.9Wh Lithium Polymer battery pack.
|
|
Minimum operating time1:
|
| Light use2: |
6 hrs |
| Moderate use3: |
3.5 hrs |
| Heavy use4: |
1.5 hrs |
|
|
Enclosure materials:
|
Polycarbonate.
|
|
Performance Characteristics
|
|
RFID engine:
|
TSL® custom module with embedded Impinj R2000.
|
|
Communication protocols:
|
TSL® ASCII 2.0 parameterised command set
Impinj binary.
|
|
Memory:
|
Optional Micro SD card (maximum 32GB capacity supported). Up to 500 million date and time stamped EPCs can be stored on a 32GB Micro SD card (separate purchase from alternative supplier).
|
|
Compatible Host devices (Bluetooth®):
|
Any Bluetooth® Host5 supporting the Serial Port Profile (SPP) or Human Interface Device (HID) profile (Android, iOS, Linux, Mac, Windows). See Bluetooth® Mode Comparison.
|
|
Compatible Host devices (USB):
|
Any USB host with FTDI VCP driver support (Windows, Linux, Mac, Android).
|
|
Environmental
|
|
Operating Temp.:
|
-10°C to 40°C
|
|
Charging Temp.:
|
5°C to 40°C
|
|
Storage Temp.:
|
Less than 1 month at -20°C to +45°C
Less than 6 months at -20°C to +35°C
|
|
Humidity:
|
5% to 85% non-condensing.
|
|
Drop Spec:
|
Multiple drops to concrete: 4 ft./1.2 m ambient, 3ft / 0.9m across the operating temperature range.
|
|
Tumble:
|
500 0.5 metre tumbles at room temperature (1,000 cycles).
|
|
Environmental Sealing:
|
IP54.
|
|
Electrostatic Discharge (ESD):
|
± 15kVdc air discharge; ± 8kVdc contact discharge.
|
|
MIL-STD 810F:
|
Meets and exceeds applicable MIL-STD 810F for drop, tumble and sealing.
|
|
RFID Performance
|
|
Standards supported:
|
EPC Class 1 Gen 2.
|
|
Nominal read range6:
|
Up to 7m (23ft).
|
|
Nominal write range6:
|
Up to 2m (6.5ft).
|
|
Field:
|
150-degree forward facing (approx.) measured from front of device.
|
|
Antenna:
|
Detachable, Circularly Polarized with optional 2D scanner.
|
|
Frequency Range:
|
EU: 865-868MHz; US: 902-928MHz.
See datasheet for other regions.
|
|
Maximum Output Power:
|
Up to 29 dBm (region dependent)
+ 3.0 dBiC Antenna
|
|
Antenna options:
|
High Performance CP.
High Performance CP with 2D Imager.
|
|
Barcode Scanning
|
|
Optional 2D Barcode Engine:
|
Optional TSL® custom 2D Barcode Scan Engine module.
|
|
Sensor Resolution:
|
1280 x 960 pixels, rolling shutter.
|
|
Field of View:
|
Horizontal: 44.5°, vertical: 33.5°
|
|
Focal Distance:
|
From front of engine: 15.24 cm (6 in.)
|
|
Aiming LED:
|
Green LED.
|
|
Illumination:
|
1 warm white LED.
|
|
Symbologies Supported:
|
1D: All major codes
2D: PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal Dutch Postal (KIX).
|
|
Communication
|
|
Bluetooth®:
|
Bluetooth® Version 2.1.
|
|
Bluetooth® Frequency Range:
|
2.4 – 2.4835 GHz.
|
|
Bluetooth® Profiles:
|
SPP Profile, HID Profile, Apple iAP.
|
|
Bluetooth® Power:
|
Class 2.
|
|
Bluetooth® TX Power:
|
3 dBm.
|
|
Bluetooth® Range7:
|
30 m.
|
|
Bluetooth® Pairing:
|
PIN, Simple Secure Pairing, NFC OOB Pairing.
|
|
Peripherals and Accessories
|
|
External interface:
|
MicroUSB connector for battery charging, and USB connectivity.
|
|
USB operating modes:
|
Tethered for real time data capture in conjunction with SmartWedge software. Download of stored scan data.
|
|
Optional charger:
|
TSL® 2136 4-Slot desktop charger.
|
|
Other Accessories:
|
Adapter mounts are available for a variety of smartphones handheld terminals.
Slimline Grip, Trigger Handle.
|
|
Regulatory
|
|
Regions
|
EU (CE), USA (FCC), Canada, Australia and more (see datasheet for details)
|
|
FCC ID
|
S6J1128
|
|
IC
|
8948A-1128
|
|
EMC
|
EN 55032:2015 +A11:2020
EN 55035:2017 +A11:2020
47 CFR Part 15B
ICES-003:2020 Issue 7
|
|
RF
|
EN 300 328 V2.2.2
EN 302 208 V3.2.0
EN 301 489-1 V2.2.3
EN 301 489-3 V2.1.1
EN 301 489-17 V3.2.4
47 CFR Part 15C 15.247
RSS-247 Issue 1
|
|
Electrical Safety
|
IEC 62368-1:2018
EN 62368-1:2020 +A11:2020
UL 62368-1:2019
CAN/CSA C22.2 No. 62368-1:19
|
|
Environmental
|
2011/65/EU (RoHS 2)
Restriction of the use of certain Hazardous Substances in electrical and electronic equipment
2015/863 (RoHS 3)
Amendment to Annex II of 2011/65/EU
|
